Chapter 1
12
UM10350_PCNC770_Manual_0916A
Preface
6.8.1 XYZ Probe Tab 84
6.8.2 Rect/Circ Tab 85
6.8.3 Probe/ETS Setup Tab 86
6.9 ADMIN Commands 86
7. Programming 87
7.1 Denions 87
7.2 G-code Programming Language 90
7.2.1 Overview 90
7.2.2 Block 90
7.2.3 Real Value 90
7.2.4 Number 90
7.3 Formang G-code Blocks 91
7.3.1 Oponal Program Stop Control – (M01 BREAK) 94
7.4 Addional G-code Formang Notes 94
7.4.1 Repeated Items 94
7.4.2 Order of Execuon 94
7.4.3 Error Handling 96
7.4.4 Modality and Modal Commands 96
7.4.5 Modal Groups 96
7.4.6 Default Modes 97
7.5 G-codes 97
7.5.1 Rapid Linear Moon – G00 99
7.5.2 Linear Moon at Feed Rate – G01 100
7.5.3 Arc at Feed Rate – G02 and G03 101
7.5.3.1 Radius Format Arc 101
7.5.3.2 Center Format Arc 102
7.5.4 Dwell – G04 105
