Chapter 1
19
UM10350_PCNC770_Manual_0916A
Preface
11. Diagrams and Parts List 217
11.1 Upper Mill Assembly (exploded view) 217
11.2 Lower Mill Assembly (exploded view) 220
11.3 Electrical Cabinet 222
11.4 Connecons 224
11.5 Stepper Connecon 225
11.6 Operator Panel 226
11.7 Ribbon Cable and Miscellaneous 227
11.8 Lubricaon System 229
