Chapter 1
20
UM10350_PCNC770_Manual_0916A
Overview
1. Overview
Tormach PCNC mills are intended for use as general purpose CNC mills. Pictured below is a typical
PCNC 770 mill set up, including several opons.
Item # Component Item # Component
1 Electrical Cabinet 6 PathPilot
®
Interface
2
Serial Number Plate
Main Disconnect Switch
7 Keyboard Table
8 Machine Arm (2)
3 Red E-stop 9 PathPilot Controller Compartment
4 Green Start Button 10 Storage Compartment
5 Operator Panel 11 Coolant Compartment
Figure 1.1
5
7
8
9
11
4
8
2
10
3
1
6
