Tormach PCNC 770

To Next Page

To Previous Page

Chapter 1

UM10350_PCNC770_Manual_0916A

Preface

Table of Contents

1. Overview 20

1.1 Specicaons (PCNC 770) 21

2. Site Planning and Prep 22

2.1 General Site Requirements 22

2.1.1 Space Requirements 22

2.2 Electrical Requirements 22

2.2.1 Grounding 22

2.2.2 Plug Paern 22

2.2.3 Ground Fault Interrupter (GFI) Use 23

2.2.4 Electrical Noise 23

2.2.5 Opons for Electrically Non-conforming Sites 23

2.2.5.1 Buck-Boost Transformer 23

2.2.5.2 Step-up/Step-down Transformer 23

2.2.5.3 Quick 220

™

Voltage Converter Power Supply 23

3. Installaon 24

3.1 Receiving, Uncrang, and Inial Inspecon 24

3.1.1 Shipment Arrival 24

3.1.2 Moving the Crate 24

3.1.3 Inial Uncrang 25

3.1.4 Shipping Damage or Shortages 25

3.2 Installaon Sequence 25

3.3 Basic Installaon Procedure 25

3.3.1 Paral Stand Assembly 25

3.3.2 Remove Tool Tray (PCNC 1100 only) 26

3.3.3 Remove Accessory Tool Box 26

3.3.4 Assembling Y-Axis (PCNC 1100 only) 26

Tormach PCNC 770 - Page 8
