OPTIONS & ALLIED TOOLING − DECO 7/10 − DECO 7a/10a − DECO 7e/10e
300236 en − 02/07 Chap. 16.3.3 /11
ADJUSTING THE 3 KNIVES IN THEIR SUPPORT.
What to do? Notes
− Replace the 3 knives in the sup
-
port.
− Install the cover by positioning
it
according to the positionin
g
mark.
− Then tighten but NOT fully th
e
3 cover screws.
− Release the knives to obtain
a
gap (e) allowing the gauge pins t
o
pass.
g
− Set the gauge (the pins (g) pla
-
ced according to the opposit
e
figure).
e
g
g
g
c
c
c
− Replace the 3 knives against the
gauge pins in this position pre-
sented opposite by turning them
on their axis by hand.
− Fully tighten the 3 cover
screws.
