OPTIONS & ALLIED TOOLING − DECO 7/10 − DECO 7a/10a − DECO 7e/10e
300236 en − 02/07 Chap. 17. /3
COMPONENTS
Item Designation
Assembly Tooling
010 Rod
020 Screwed sleeve
250 Roller bearing
260 Nut
Locking System
030 Notched disk
040 Rear spindle-spring bushing, with bores
050 Locking pin
060 Cylinder
070 Cylinder cover
080 Locking-mechanism support
200 Cylinder fastening screw
210 Locking-mechanism fastening screw
240 Disk fastening screw
240 Vis de fixation du disque
1010 Bague SEEGER
DISMOUNTING
What to do ? Notes
− Take down the headstock guard.
− Remove Barguide-Tube Support 100.
− Disconnect the air supply tube.
− Unscrew two Screws 210 or two Screws
230.
− Remove the locking mechanism.
− Unscrew Screws 240.
− Withdraw Notched Disk 030.
− Remount the headstock guard.
MOUNTING
What to do ? Notes
− Replace Bushing 040: for details see overleaf
− Fit Notched Disk 030: for details see overleaf
− Fit the locking mechanism: for details see overleaf
Angular Setting of Spindle Lock see below
