OPTIONS & ALLIED TOOLING − DECO 7/10 − DECO 7a/10a − DECO 7e/10e
300236 en − 02/07 Chap. 19. /3
Advantages Disadvantages
Feed length not affected 2 tool stations required
Compatible with all guidebush types Swarf
Reliable Spindle stop required
No hydraulics
Adjustable clawing force
SETTING CLAWING FORCE
Note:
Make sure to set the clawing force of both claws at a time.
SETTING CLAWING FORCE of Bar Retention Claws
What to do ? How ? What for ? Notes
Dismounting
Loosen Locking Screw 040.
Remove the V-claw and the spring.
Setting
Use one of the two available Compres-
sion Spings 200 or 210 ...
... acc. to their different charac-
teristics.
Mounting
Fit in place the V-claw and the spring.
Tighten Locking Screw 040.
>>>
To Next Page
