OPTIONS & ALLIED TOOLING − DECO 7/10 − DECO 7a/10a − DECO 7e/10e
300236 en − 02/07 Chap. 20.1 /3
COMPONENTS
Item Description
10 Thrustor support
20 Thrustor bracket
30 Bracket with 4mm-∅ hole
40 Guiding steady
50 4mm-∅ ejection rod
110 3mm-∅ ejection rod
260 Thrustor
MOUNTING LONG PART EJECTOR
To start with: Free Positions T41 and T42.
. Caution ! For S5-Spindle Drive (305053), replace the belt guard with
Guard 90.
See S5-Spindle Drive, Instructions 300231, Para. 10.3.
Install the pneumatic control and connect it electrically,
See Long-Part Evacuation Pneumatics, Para. 19.3.
What to do ? Notes
Mounting
Get the preassembled unit ready: in T41, T42.
Screw in two Screws 240 (M8 x 16)
...
... without tightening them.
Fix Guiding Steady 040 to the face
of the vertical ...
... with two Screws 230 (M6 x 16)
but without tightening them.
Align the thrustor with Ejection Rod
50 and Guiding Steady 40.
Tighten all Screws 240 and 230.
Set Ejection Rod 50 at 30 mm off
the tool line.
Connect the air pipes. See the control diagram and oper-
ation in Para. 19.3.
Adjust the advance / return rates of
the thrustor.
Ditto.
