AssemblingtheBladeSpindle

g189007

Figure299

1.Bearing3.Largesnapring

5.Outerspacer

2.Spacerring

4.Innerspacer

Note:Areplacementspindlebearingsetcontains2bearings,aspacerring,

andalargesnapring(items1,2,and3inFigure299).Youcannotpurchase

thesepartsseparately.Also,donotmixthebearingsetcomponentsfromone

deckspindletotheanother.

Note:Areplacementbearingspacersetincludestheinnerspacerandouter

spacer(items4and5inFigure299).Donotmixthebearingspacersfromone

deckspindletotheanother.

IMPORTANT

Ifnewbearingsareinstalledintoausedspindlehousing,itisnot

necessarytoreplacetheoriginallargesnapring.Iftheoriginalsnap

ringisingoodconditionwithnosignofdamage(e.g.,spunbearing),

leavethesnapringinthehousinganddiscardthesnapringthat

comeswiththenewbearings.Ifthelargesnapringisdamaged,

replacethesnapring.

1.Ifthelargesnapringwasremovedfromthespindlehousing,installthesnap

ringintothehousinggroove.

Note:Ensurethatthesnapringisfullyseatedinthehousinggroove.

2.Installtheouterspacerintothetopofthespindlehousing.

Note:Ensurethattheouterspacertsagainstthesnapring.

Groundsmaster

3280-D/3320

Page10–11

CuttingUnits:ServiceandRepairs

05138SLRevB
