InstallinganAdjustableFitting

1.Ensurethatallthethreads,thesealingsurfacesoftting,andthecomponent

portarefreeofburrs,nicks,scratches,orunwantedmaterial.

2.Tohelppreventahydraulicleak,replacetheO-ringwhenyouopenthe

connection.

g221224

Figure40

1.Locknut2.Back-upwasher

3.O-ring

3.LightlylubricatetheO-ringwithcleanhydraulicuid.Ensurethatthethreads

ofthettingarecleanwithnolubricantapplied.

g221225

Figure41

4.Turnbackthelocknutasfaraspossible.Ensurethattheback-upwasheris

notlooseanditispushedupasfaraspossible(Step1inFigure41).

IMPORTANT

Beforeinstallingthettingintotheport,determinethematerialof

whichtheportismade.Installingattingintoanaluminumport

requiresareducedinstallationtorque.

5.Installtheadjustablettingintotheportbyhanduntilthewashercontactsthe

faceoftheport(Step2inFigure41).

6.Iftheadjustablettingneedstoalignwithanothercomponent,rotatethetting

counterclockwiseuntilitisalignedtothedesiredposition(Step3inFigure

41).Donotrotatetheadjustablettingmorethan1turncounterclockwise.

Groundsmaster

3280-D/3320

Page5–13

HydraulicSystem:GeneralInformation

05138SLRevB
