6
© 2011 - 2015 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO5540C/6540C/6550C/5560C/6560C/6570C
SETTING ADJUSTMENT
6 - 41
6.2.11 Beam level conversion setting
The beam level for 4 divided smoothing is set at the Black Mode. This adjustment enables to adjust the
dot size.
<Adjustment Mode (05)>
Make a test copy and compare the image obtained with the current settings; if necessary, make
adjustments according to the following procedure.
<Procedure>
(1) While pressing [0] and [5] simultaneously, turn the power ON.
(2) Key in a code and press the [START] button.
(3) Key in a sub-code and press the [START] button.
(4) Key in an adjustment value.
(To correct a value once keyed in, press the [CLEAR] button.)
(5) Press the [OK] or [INTERRUPT] button to store the value. The equipment goes back to the
ready state.
(6) Press the [FAX] button and then press the [START] button to make a test copy.
(7) If the desired image quality has not been attained, repeat step (2) to (6).
Notes:
• The setting value must increase as the beam level number (0 to 4) becomes higher. Do not
increase this order when setting the values.
• Usually, beam level 4 / 4 is most effective on black mode.
<e-STUDIO5540C/6540C/6550C only>
Notes:
• When this adjustment was performed, perform “Automatic gamma adjustment (black) (05-
7165)” as well because the density reproduction level in the black mode will vary. In addition
to performing the code 05-7165, perform the code 05-7869 or 05-7871 individually because
the result of this adjustment will not be reflected to the color & black integrated pattern.
• After this adjustment, set “1” in 08-7625 so that the correction result of the Black Mode is not
reflected on “Automatic Calibration”.
Code Item to be adjusted Remarks
7212-0 Beam level 0/4 The smaller the value is, the smaller the beam width
becomes. Therefore, the smaller dot is reproduced
accordingly. Acceptable values: 0 to 255
(Default: Level 0/4: 0, Level 1/4: 63, Level 2/4: 127,
Level 3/4: 191, Level 4/4: 255)
7212-1 Beam level 1/4
7212-2 Beam level 2/4
7212-3 Beam level 3/4
7212-4 Beam level 4/4
To Next Page
