Hardware Interfaces

D-13

B5 -5 VDC -5 volt power

B6 DRQ2 Out DMA request 2

B7 -12 VDC -12 volt power

B8 NOWS_L Out No wait state

B9 +12 VDC +12 volt power

B10 GND In/Out Ground

B11 SMWT_L In System memory write

B12 SMRD_L In System memory read

B13 IOW_L In I/O write

B14 IOR_L In I/O read

B15 DAK3_L In DMA acknowledge 3

B16 DRQ3 Out DMA request 3

B17 DAK1_L In DMA acknowledge 1

B18 DRQ1 Out DMA request 1

B19 REFRESH_L In/Out DRAM refresh control

B20 BCLK In Bus clock

B21 IRQ7 Out Interrupt request 7

B22 IRQ6 Out Interrupt request 6

B23 IRQ5 Out Interrupt request 5

B24 IRQ4 Out Interrupt request 4

B25 IRQ3 Out Interrupt request 3

B26 DAK2_L In DMA acknowledge 2

B27 TC In Terminal count

B28 BALE In Bus address latch enable

B29 +5 VDC +5 volt power

B30 OSC In System oscillator

B31 GND In/Out Ground

C1 SBHE_L In System bus high enable

Table D-9 ISA Bus Pin Definition (continued)

Pin Signal In/Out Description
