Analog input modules
D300529 0115 - BL67 I/O modules6-50
0 … 20 mA unipolar Diagnostics dec. hex.
current value
M
= (dec. value × 6,104 × 10
-4
) mA
> 20.2000 mA
at ↑ DIA Measured value out
of range ON
32767 7FFF
≤ 20.1000 mA
at ↓ DIA Measured value
out of range OFF
32767 7FFF
20.0000 mA
nominal range
32767 7FFF
19.9994 mA 32766 7FFE
………
10.0003 mA 16384 4000
………
0.0006104 mA 1 0001
≤ 0.0000 mA 0 0000
≥ -0.1 mA
at ↑ DIA Measured value
out of range OFF
00000
< -0,2 mA
at ↓ DIA Measured value
out of range ON
00000
4 … 20 mA unipolar Diagnostics dec. hex.
current value
M
= (dec. value × 4,883 × 10
-4
) mA
> 20.2000 mA
at ↑ DIA Measured value
out of range ON
32767 7FFF
≤ 20.1000 mA
at ↓ DIA Measured value
out of range OFF
32767 7FFF
20.0000 mA
nominal range
32767 7FFF
19.9995 mA 32766 7FFE
………
12.00024 mA 16384 4000
………
4.0004883 mA 1 0001
≤ 4.0000 mA 0 0000
≥ 3,7000 mA
at ↑ DIA Measured value
out of range OFF
00000
< 3.6000 mA
at ↓ DIA Measured value
out of range ON
00000
≥ 3,0000 mA
at ↑ DIA Wire break OFF 0 0000
< 2.9000 mA
at ↓ DIA Wire break ON 0 0000
