turck BL67 - Page 148

Analog input modules
D300529 0115 - BL67 I/O modules6-60
0 … 10 V unipolar Diagnostics dec. hex.
voltage value U
M
= (dec. value × 0,001) V
≥ 11,000 V
overflow
11000 2AF8
≤ 10,999 V 10999 2AF7
≥ 10.500 V
over-
steering
at ↑ DIA Measured value
out of range ON
10500 2904
≤ 10.250 V
at ↓ DIA Measured value
out of range OFF
10250 280A
10.001 V 10001 2711
10.000 V
nominal range
10000 2710
………
5.000 V 5000 1388
………
0.001 V 1 0001
0.000 V 0 0000
≥ - 0,05 V
underflow
at ↑ DIA Measured value
out of range OFF
00000
< -0,10 V
at ↓ DIA Measured value
out of range ON
00000
0 … 20 mA unipolar Diagnostics dec. hex.
current value
M
= (dec. value × 0,001) mA
≥ 22,000 mA
overflow
at ↑ DIA
Overflow/underflow ON
22000 55F0
≤ 21.999 mA
at ↓ DIA
Overflow/underflow OFF
21999 55EF
21.001 mA 21001 5209
≥ 21.000 mA
over-
steering
at ↑ DIA Measured value
out of range ON
21000 5208
≤ 20.500 mA
at ↓ DIA Measured value
out of range OFF
20500 5014
20.001 mA 20001 4E21
20.000 mA
nominal range
20000 4E20
………
10.000 mA 10000 2712
………
0.001 mA 1 0001
0.0000 mA 0 0000
