D300529 0115 - BL67 I/O modules
6-59
BL67-4AI-V/I, voltage-/current measurement
Value representation process automation (NE 43)
 16-bit-representation
The hexadecimal value transmitted by the module has to be interpreted as decimal value, which corre-
sponds, if multiplied with a defined factor, to the analog value.
-10 … 10 V bipolar Diagnostics dec. hex.
voltage value U
M
= (dec. value × 0,001) V
≥ 11,000 V
overflow
11000 2AF8
≤ 10.999 V 10999 2AF7
≥ 10.500 V
over-
steering
at ↑ DIA Measured value
out of range ON
10500 2904
≤ 10.250 V
at ↓ DIA Measured value
out of range OFF
10250 280A
10.001 V 10001 2711
10.000 V
nominal range
10000 2710
………
5.000 V 5000 1388
………
0.001 V 1 0001
0.000 V 0 0000
-0.001 V -1 FFFF
………
-5.0000 V -5000 EC78
………
-10.000 V -10000 D8F0
- 10,001 V
under-
steering
-10001 D8EF
-10.250 V
at ↑ DIA Measured value
out of range OFF
-10250 D7F6
-10.500 V
at ↓ DIA Measured value
out of range ON
-10500 D6FC
-10.501 V
underflow
-10501 D6FB
-10.999 V -10999 D509
≤ -11.000 V -11000 D508
