Analog input modules
D300529 0115 - BL67 I/O modules6-62
 12-bit-representation (left-justified)
The 12-bit-representation (left-justified) in process automation corresponds to the 15-bit-representa-
tion in which the lower 4 bits of the analog value are overwritten with diagnostic data.
-10 … 10 V bipolar Diagnostics dec. hex.
voltage value U
M
= (dec. value × 0,001) V
≥ 11,008 V
overflow
11008 2B0×
≤ 10.992 V 10992 2AF×
10.512 V
at ↑ DIA Measured value
out of range ON
10512 291×
≥ 10.496 V
over-
steering
10496 290×
≤ 10.256 V
at ↓ DIA Measured value
out of range OFF
10256 281×
10.016 V 10016 272×
10.000 V
nominal range
10000 271×
…
4.992 V 4992 138×
………
0.016 V 16 001×
0.0000 V 0 000×
-0.016 V -16 FFF×
………
-4.992 V -4992 EC8×
………
-10.000 V -10000 D8F×
- 10,016 V
under-
steering
-10016 D8E×
-10.256 V
at ↑ DIA Measured value
out of range OFF
-10256 D7F×
-10.496 V -10496 D70×
-10.512 V
underflow
at ↓ DIA Measured value
out of range ON
-10512 D6F×
-10.992 V -10992 D51×
≤ -11.008 V -11008 D50×
