D300529 0115 - BL67 I/O modules
9-27
BL67-8XSG-PD
 BL67-B-1M23-VI
Channel related diagnostics is not possible with this base module. The sensor su
pply is current lim-
ited to 4A via gateway or power feeding module.
Figure 9-20:
0
Figure 9-21:
81
9
712102
54
63
11
v
1 = Signal 0
2 = Signal 1
3 = Signal 2
4 = Signal 3
5 = Signal 4
6 = Signal 5
7 = Signal 6
8 = Signal 7
9 = V
SENS
10 = V
SENS
11 = V
SENS
12 = GND
BL67-B-1M23-VI
Pin assignment
BL67-8XSG-PD
with
BL67-B-1M23-VI
