As shown in the Figure 5-14, the users in Building 1 could access the Internet through
the Gateway (IP address: 192.168.1.1). If the Device B is wirelessly connected to
Device A, the users in Building 2 could access the Internet too. We could use the
WDS function of the Device to realize it.
The related parameters of Device A are as
follows:
IP Address of LAN port 192.168.1.253/24 Gateway address 192.168.1.1
SSID Customer MAC 0022AABA767C
Wireless mode 11b/g/n Mixed Channel 6
Security mode TKIP Pre-shared key 123456789
2) Analysis
We can connect Device B to Device A wirelessly by using one of the following ways.
Solution I: Devices A and B are set to Repeater Mode.
Solution II: Devices A and B are set to Bridge Mode.
Solution III: Devices A and B are set to Repeater Mode, Bridge Mode respectively.
Solution IV: Devices A and B are set to Repeater Mode, Lazy Mode respectively.
Solution V: Devices A and B are set to Bridge Mode, Lazy Mode respectively.
3) Configuration steps:
Solution I: Both are Repeater Mode
Step 1 Login to the Device B.
Step 2 Go to Network > LAN page to configure the IP address of Device B (Device A
and Device B should be on the same network segment), with the gateway
address directed to the export gateway.
Step 3 Go to Wireless > Basic page, configure the Operation mode of Device B as
Repeater Mode, with the MAC address of Device A as the MAC address of
Device B, and the configuration content is shown in the figure below:
