4-20 SHB WL34 * 2.0
4 Travel drive
Cardan shaft
5. Clean the contact area and the threaded bolts on the rear axle 5.
6. Apply locking compound to the stud bolt and the contact area.
7. Slide the cardan shaft onto the stud bolts on the rear axle.
8. Screw nuts 6 onto the stud bolts and tighten them.
9. Remove lock from oscillating articulation (see Operator’s Manual).
10.Release the parking brake.
