SHB WL34 * 2.0 5-5
Axles 5
Rear axle
5.2 Rear axle
Overview
Removing/installing the rear axle
Preparations
1. Park the machine on firm, level and dry ground.
2. Apply the parking brake.
3. Lower the loader unit to the ground.
4. Stop the engine.
5. Block the oscillating articulation (see Operator’s Manual).
Injury hazard due to heavy component!
The rear axle weighs approx. 220 kg.
Use suitable lifting gear to remove and install the rear axle.
Weight Designation
220 kg Rear axle
Axles
Rear axle
