SHB WL34 * 2.0 6-11
Brake 6
Service/parking brake
Removing/installing the Bowden cable for the fixed brakes
4. Dismount the holder for the Bowden cable 1. To do this, remove the
nut on the back side.
5. Loosen the nuts 2 on the inner and outer sides of the cabin.
6. Pull out the Bowden cable through the opening.
7. Ensure access to the Bowden cable up to the front axle. To do this,
remove all cable ties.
8. Pull off metal sleeve 3 a little.
9. Separate connection to front axle 4 and remove Bowden cable.
Install in the reverse order.
Fig. 176
1
2
Fig. 177
3
4
