9 Electrical system
Malfunctions of the machine electronics
9.6 Malfunctions of the machine electronics
Warning lights 20 and 21 indicate errors issued by the machine’s control
unit.
Warning lights 22 and 23 indicate errors issued by the engine’s control
unit.
These warning lights illuminate during engine start and go out again. If
one of the warning lights flashes or illuminates during machine operation,
an error code is displayed at the same time in the indicating instrument.
Error message on display with symbol
In case of a malfunction during machine operation, the operating hours
and engine speed readout is replaced by a symbol. The following symbols
can appear as error messages.
Machine display Symbol
Indicator for air filter pollution
Indicator for engine coolant level
Indicator for water in fuel
Indicator for hydraulic oil filter pollution
Indicator for hydraulic oil temperature
Electrical system
Malfunctions of the machine electronics
