Wacker Neuson WL34 - Page 286

9-26 SHB WL34 * 2.0
9 Electrical system
Diagrams
9.19 Electrical diagram – Brake light lighting (FG06-03)
N004:80/FG04-1
E003/FG06-2
H026/FG06-2
E027/FG6-2
H024/FG06-2
E001/FG04-2
S040:2/FG10-1/2
15
50
15
50
31 31
3030
5
54
79
AB
5
6
4317
6
26
F007
10 A
GN-1,5
X002
GY
S009
BK/RD
BK/RD
Engine
404D-22
TD2011
404F-22
X035
BK/RD BK/RD
N004
H021
21 W
H020
21 W
GY GY
X053
GY-0,75 GY
XX04
GYGY
XX05
BK-1,5 BK-1,5
X037
BK GY GY GY GY
X035 X035
BK-1,5 BK-1,5
GN-1,5
43
12
Assign-
ment
Designation
F007 Brake lights
H020 Brake lights
H021 Brake lights
N004 Traction electronics
S009 Brake light switch
X002 Instrument panel
X035 Rear indicator light
X037 Trailer socket
X053 Reversing light
XX04 7 pole socket for front attachments
XX05 Trailer socket
1 Option: 7-pole plug receptacle for front attachments
1
