SHB WL34 * 2.0 11-3
Cabin 11
Ignition lock
11.2 Removing/installing the starter
1. Remove the steering wheel – see “Removing/installing the steering
wheel” on page 7-2.
2. Remove screws 1.
3. Remove screws 2.
4. Raise the instrument panel.
5. Remove screws 3.
6. Remove screws 4.
7. Slide the bellows downward.
8. Fold the plastic trims aside.
Fig. 274
1
Fig. 275
2
Fig. 276
3
Fig. 277
4
Cabin
Ignition lock
