1 Getting started with the Alliance e2695 Separations Module
42 July 29, 2013, 715003794 Rev. B
The e2695 has four column selection valve options, as described in the
following table.
The software automatically detects the presence and type of column selection
valve when you power-on the separations module. You can specify column
selection:
• Using the front panel (see “Perform direct functions” on page 123)
• Through the separation method (see “Create and edit separation
methods” on page 146)
• As part of a function in the sample set method (see “Create and edit a
sample set” on page 174)
The Status screen shows the currently selected column or flow path for only
those valves detected by the software.
Column selection valve options:
Description
Software
detection
Controlled by
2 Column (6 port, 2 position) No I/O
3 Column Yes e2695 software
6 Column Yes e2695 software
2 Column- Regeneration
(10 port, 2 position)
Yes e2695 software
