Options and accessories
July 29, 2013, 715003794 Rev. B 43
e2695 column heater:
Two-column selection valve
The firmware does not recognize the 2-column selection valve (6 port, 2
position) option. Instead, the option is controlled via one of the four I/O event
switches on the separations module’s rear panel. You select one column by
turning the switch to Off and the second column by turning the switch to On.
Three-column selection valve
The 3-column selection valve selects any of three column positions. It is
preconfigured before shipment, but you can reconfigure it. For more
information, see “Connect the column selection valve” on page 64.
Location
of optional
column
selection
valve
