2 Install the e2695 Separations Module
52 July 29, 2013, 715003794 Rev. B
detector, on the front left-hand side. You must install the drain fitting
for the 2998; the rest are pre-installed.
2. Seat the detector on the detector base.
3. Make sure the end of the detector drip tray tubing protrudes from the
detector drain fitting into the black-colored drip tray, as shown in the
figure below. In detectors with longer drip tray tubing, you may need to
bend the tubing slightly to the right or left to ensure that the end of the
tubing lays inside the drip tray.
Drip tray preparation steps, by detector model:
Detector model Drip tray tubing and fitting preparation steps
2414 1. Cut a 3” length of the 1/4” ID convoluted
tubing (WAT241095) supplied in the kit.
2. Attach the tubing to the fitting on the
underside of the detector.
2424 1. Cut a 1-1/4” length of the Tygon tubing
(430000604) supplied in the kit.
2. Attach the tubing to the barbed fitting on the
underside of the detector.
2475 Tygon tubing is supplied pre-cut and already
connected to the fitting on the detector. No
preparation is needed.
2489 1. Cut a 2” length of the 5/16” ID convoluted
tubing (430003945) supplied in the kit.
2. Attach the tubing to the elbow fitting on the
underside of the detector.
2998 1. Press the stainless steel barbed fitting
(405016495) supplied in the kit into the
matching hole located on the front left-hand
side, on the underside of the detector.
2. Cut a 1” length of the 3/8” ID convoluted
tubing (430001556) supplied in the kit.
3. Attach the tubing to the barbed fitting.
