2 Install the e2695 Separations Module
76 July 29, 2013, 715003794 Rev. B
IEEE-488 connections
Use the IEEE-488 interface connector (see the figure “Rear panel of the
separations module:” on page 49) to connect the separations module to these
IEEE-488 devices:
• Waters 2487, 486, 2414, 2410, and 410 detectors
• BusLAC/E card in an Empower software system, a network LAC/E
module, or a LAC/E
32
Acquisition Server (Empower software)
• General purpose instrument board of a MassLynx computer
Requirements:
• You cannot use the separations module’s IEEE-488 interface at the
same time you are using its Ethernet port for communications.
• For remote control, you can only configure the separations module for
IEEE-488 communications if it belongs to one of these configurations:
• Where the separations module and detector(s) communicate with
the data system via IEEE-488
• Where the separations module and data system communicate via
IEEE-488, and include one or more detectors that can only
communicate with the data system via Ethernet (e.g., Waters 2998,
2489, 2475, 2424, e-SAT/IN module-connected, or 3100 Mass
Spectrometer Detector. See “Supported IEEE-488 and Ethernet
configurations” on page 38.)
The IEEE-488 connector in the separations module mates with a standard
IEEE-488 cable.
RS-232 output parameters displayed in the configuration screen:
Parameter Value
Device None, 746 Integrator, Serial
Printer, BCD output
Baud rate 1200, 2400, 9600
