Add hardware options
July 29, 2013, 715003794 Rev. B 79
• Union (part number WAT097334)
To remove the side panel:
Note: This procedure applies only to a separations module with no column
heater or column heater/cooler option installed. If the column heater or
column heater/cooler option is installed, see page 201 for instructions on how
to remove the side panel of the separations module.
1. Power-off the separations module, and disconnect it from the electrical
outlet.
2. Remove the 2 screws that secure the separations module’s right-hand
side panel.
3. Slide the side panel to the rear, off the rear panel posts.
To add a sample loop to the factory-installed 100-µL loop:
1. Use the 5/16-inch wrench to disconnect the sample loop from the
pressure transducer (see the figure “Disconnect the sample loop:” on
page 80).
2. Connect the open end of the existing sample loop to one end of the union.
3. Connect the other end of the union to the new sample loop.
4. Connect the open end of the new sample loop to the pressure transducer.
5. Use the wrenches to tighten the connections.
6. Connect the power cable, and power-on the separations module.
7. In the Configuration screen, enter the new sample loop volume (see
“Configure the separations module” on page 91).
8. Perform a purge and compression check, and check for leaks (see “Purge
the system” on page 108 for the purge procedure).
Warning: To avoid having your fingers pinched by movement of the
sample carousel, do not remove the cover plate on the side of the sample
compartment.
