114 EN MEDUCORE Standard
2
WM 68401 04/2021
5 Function check
1. Connect the ECG cable to the ECG connection for ECG cable.
Alternatively:
Connect the ECG cable to the ECG connection for ECG cable
using the connection for 12-lead ECG extension cable.
2. To check 12-lead ECG recording and assessment:
Connect the 12-lead ECG extension cable to the ECG cable
with connection for 12-lead ECG extension cable.
