WM 68401 04/2021
MEDUCORE Standard
2
EN 115
5 Function check
3. Connect the terminals of the ECG cables used to an ECG
simulator:
• ECG simulator, 6-lead ECG, shockable WM 45444
• ECG simulator, 12-lead ECG, shockable WM 45445
4. Switch on the ECG simulator and set a sinus rhythm.
5. Switch on the device (see “6.1 Switching on the device”,
page 118).
The start menu appears.
6. Select the Adult patient group (see “6.4 Selecting patient
group”, page 120).
7. If the ECG curve is shown in the center curve field: Press the
Lead button to display all ECG leads.
8. Assess the ECG leads:
• All ECG leads must be displayed.
• All ECG leads must display the set sinus rhythm.
• Shaking the cable must not result in one or more ECG leads
either not being displayed or being displayed with faults.
9. If ECG leads are not shown or are shown with faults: Replace
ECG cable.
10. Switch off the device (see “6.2 Switching the device off”,
page 119).
11. Disconnect the ECG simulator from the ECG cable used.
Result The ECG cables have been checked.
In principle, any ECG simulator can be used. Alternatively, the ECG
cables can also be tested on a volunteer test subject.
