WM 68401 04/2021
MEDUCORE Standard
2
EN 217
6 Operation
6.21.2 Exporting service data to SD card
Requirement • There is an SD card in the SD card slot.
• The user menu is activated (see “10.1 Navigating the user
menu”, page 252).
Alternatively:
The operator menu is activated (see “13.1 Activating the
operator menu”, page 307).
1. Select System settings | Service | Export service data to SD
card.
2. Confirm with the OK function button.
The export process starts.
3. If export is successful: Remove the SD card (see “4.6.2
Removing the SD card”, page 93).
4. Insert the SD card in the SD card slot of a PC.
5. E-mail service data to WEINMANN Emergency Technical
Service for further analysis.
Result Service data have been exported to the SD card and made available
to WEINMANN Emergency Technical Service.
