Direct voltage
Type of protection against electric shock: Protection class II device
IP55 Degree of protection against
• Ingress of solid objects
• Ingress of dust
• Ingress of water with harmful effect
IPX1
IPX7 Degree of protection against temporary immersion in water
IPX2
Degree of protection against water dripping at an angle, 15° relative to the normal
operating position
Input voltage
Output voltage
Input (12 V - 15.1 V, 30 W)
Input voltage (12 V - 15.1 V)
Line power indicator: The LED comes on when the charging station is connected to line
power.
Battery fault, if red fault indicator on
Battery status
Audibly engage battery
Pad Connection for master cable
SpO2 Connection for pulse oximetry sensor connecting cable
ECG Connection for ECG cable
NIBP Connection for NIBP cuff connector tube
E
max
= 200 J Maximum energy delivered
Symbol Description
