392 EN MEDUCORE Standard
2
WM 68401 04/2021
19 Labeling
Marks the button which can be used to charge the shock capacitor.
Marks the two buttons which have to be pressed simultaneously for shock delivery.
APEX
Marks the paddle which has to be held at the apex position.
STERNUM
Marks the paddle which has to be held at the sternum position.
On/Off button
For other labeling, see the following instructions for use:
• Defibrillation electrodes
• ECG electrodes
•NIBP cuffs
Symbol Description
