WM 68401 04/2021
MEDUCORE Standard
2
EN 43
3 Description
11 Top curve field
Displays the ECG lead via the defibrillation electrodes/
paddles (Pad, II).
12
R wave marking (only with Cardioversion
option)
Marks the R waves detected by the device in the ECG
if SYNC has been activated in the application menu.
13 Center curve field
Displays the selected ECG lead:
• I, II, III, aVR, aVL or aVF
• V1 to V6 (only with 12-lead ECG extension cable
and only with 12-lead ECG option)
14 Bottom curve field Displays the plethysmogram.
15 Energy Allows shock energy to be adjusted.
16 ECG lead selection
Allows switching between the ECG leads displayed in
the center curve field:
• Limb leads acc. to Einthoven (I, II, III)
• Limb leads acc. to Goldberger (aVR, aVL, aVF)
• Chest wall leads acc. to Wilson (V1 to V6) (only
with 12-lead ECG extension cable and only with
12-lead ECG option)
17 Monitor mode Provides access to monitor mode.
18 Charge Charges the shock capacitor.
19 ECG calibration mark
Displays the section corresponding to 1 mV of the
ECG signal.
20 AED mode Provides access to AED mode.
21 NIBP Displays blood pressure.
22 Alarm limits Displays the set alarm limits.
23 Pulse Displays pulse rate.
24 SpO
2
Displays oxygen saturation.
25 HR Displays heart rate.
26 Upload symbol
• Indicates that e-mail delivery 12-lead ECG has
been started (only with E-mail delivery 12-lead
ECG option).
• Indicates whether the last e-mail delivery started
was successful (only with E-mail delivery 12-lead
ECG option).
• Indicates whether the function check has been
uploaded to WEINMANN Connect successfully.
• Indicates whether the session data have been
uploaded to WEINMANN Connect successfully
(only with Upload session data option).
• Indicates whether the service data have been
uploaded to WEINMANN Emergency
successfully.
No. Designation Description
