46 EN MEDUCORE Standard
2
WM 68401 04/2021
3 Description
6 Alarm indicator
Indicates the status of audio alarm output:
• Audio alarm output active
• Audio alarm output muted/paused
• Audio alarm output canceled
7 Patient group
Displays the selected patient group:
•Adult
•Child
•Infant
8 Mode indicator Indicates the mode currently selected.
9 Alarm limits Displays the set alarm limits.
10 History
Shows the time and values of the last three NIBP
measurements.
11 Top curve field
Displays the ECG lead via the defibrillation electrodes/
paddles (Pad, II).
12 Center curve field
Displays the selected ECG lead:
• I, II, III, aVR, aVL or aVF
• V1 to V6 (only with 12-lead ECG extension cable
and only with 12-lead ECG option)
13 Bottom curve field Displays the plethysmogram.
14 Heart rate tone/pulse tone Switches the heart rate tone/pulse tone on and off.
15 ECG lead selection
Allows switching between the ECG leads displayed in
the center curve field:
• Limb leads acc. to Einthoven (I, II, III)
• Limb leads acc. to Goldberger (aVR, aVL, aVF)
• Chest wall leads acc. to Wilson (V1 to V6) (only
with 12-lead ECG extension cable and only with
12-lead ECG option)
16
Manual mode (only with Manual
defibrillation option)
Provides access to manual mode.
17 ECG calibration mark
Displays the section corresponding to 1 mV of the
ECG signal.
18 AED mode Provides access to AED mode.
19 NIBP Displays blood pressure.
20 Pulse Displays pulse rate.
21 SpO
2
Displays oxygen saturation.
22 HR Displays heart rate.
23 DIA
Displays the diastolic measured value for an NIBP
measurement.
24 SYS
Displays the systolic measured value for an NIBP
measurement.
No. Designation Description
