WM 68401 04/2021
MEDUCORE Standard
2
EN 47
3 Description
25 Upload symbol
• Indicates that e-mail delivery 12-lead ECG has
been started (only with E-mail delivery 12-lead
ECG option).
• Indicates whether the last e-mail delivery started
was successful (only with E-mail delivery 12-lead
ECG option).
• Indicates whether the function check has been
uploaded to WEINMANN Connect successfully.
• Indicates whether the session data have been
uploaded to WEINMANN Connect successfully
(only with Upload session data option).
• Indicates whether the service data have been
uploaded to WEINMANN Emergency
successfully.
26 Printer symbol (only with Printing option)
Indicates whether the printer is connected to the
device.
27 WiFi symbol
• Indicates whether the default network can be
reached.
• Displays the signal strength of the WiFi
connection: The more bars displayed, the
stronger the signal.
No. Designation Description
