50 EN MEDUCORE Standard
2
WM 68401 04/2021
3 Description
No. Designation Description
1 Limb electrodes
Indicates that the limb electrodes are connected. The
names of the limb electrodes change depending on
the set electrode marking (ERC or AHA) (see “13.10
12-lead ECG settings (only with 12-lead ECG
option)”, page 335).
2 Progress display
Indicates how far the 12-lead ECG has already
recorded.
3 Progress display in percent
Indicates how many percent of the 12-lead ECG has
already been recorded.
4 Top curve field
Displays the selected ECG lead: I, II, III, aVR, aVL, aVF,
V1, V2, V3, V4, V5, V6
5 Instruction field Gives instructions on what to do.
6 Cancel Cancels a 12-lead ECG recording.
7 6-curve view Displays 6 ECG leads simultaneously.
8 Date/time
Displays the date and time of the 12-lead ECG
recording.
9 ECG lead selection
Allows you to switch between ECG leads:
• Limb leads acc. to Einthoven (I, II, III)
• Limb leads acc. to Goldberger (aVR, aVL, aVF)
• Chest wall leads acc. to Wilson (V1 to V6)
10 Patient data Display the age and gender of the patient.
11 ECG calibration mark
Displays the section corresponding to 1 mV of the
ECG signal.
12 3-curve view Displays 3 ECG leads simultaneously.
13 Amplitude scaling
Here you can set the amplification of the ECG signal
and thus the height of the ECG curve.
14 Feed rate
Here you can set the feed rate of the ECG curve display
and so change the time resolution.
15 ECG lead
Displays the selected ECG lead: I, II, III, aVR, aVL, aVF,
V1, V2, V3, V4, V5, V6
16
E-mail delivery (only with E-mail delivery
12-lead ECG option)
Here you can deliver the 12-lead ECG by e-mail.
17
Upload symbol (only with E-mail delivery
12-lead ECG option)
• Indicates that e-mail delivery 12-lead ECG has
been started.
• Indicates whether the last e-mail delivery started
was successful.
18 Patient ID
Displays the ID of the 12-lead ECG recorded. This ID
also appears in the PDF and in the printout and allows
the 12-lead ECG to be identified.
