WM 68401 04/2021
MEDUCORE Standard
2
EN 51
3 Description
19 Chest wall electrodes
Indicates whether the chest wall electrodes are
connected. The names of the chest wall electrodes
change depending on which electrode marking is set
(ERC or AHA) (see “13.10 12-lead ECG settings (only
with 12-lead ECG option)”, page 335). Connected
chest wall electrodes are indicated by a check mark.
20 Last 12-lead ECG recording
Here you can call up the last 12-lead ECG of the
current session.
21 Start Starts the 12-lead ECG recording.
No. Designation Description
