FRONT BRAKE
4-29
Disassembling the front brake calipers
Order Job/Parts to remove Q’ty Remarks
The following procedure applies to both of
the front brake calipers.
1 Brake pad bolt 2
2 Brake pad spring 2
3 Front brake pad 4
4 Brake caliper piston 4
5 Brake caliper piston seal 8
6 Bleed screw 1
7 Bleed screw 1 Right side only.
For assembly, reverse the disassembly pro-
cedure.
T
R
.
.
17 Nm (1.7 m
•
kg, 12 ft
•
Ib)
T
R
.
.
6 Nm (0.6 m
•
kg, 4.3 ft
•
Ib)
T
R
.
.
6 Nm (0.6 m
•
kg, 4.3 ft
•
Ib)
New
New
New
New
LS
1
2
2
3
4
4
1
6
3
7
5
5
5
5
To Next Page
