FEATURES
1-13
ABS ECU (electronic control unit)
The ABS ECU “1” controls the ABS and is installed under the storage compartment. To protect the ABS
ECU from water damage, it is protected by a cover “2”.
As shown in the block following diagram, the ABS ECU receives wheel sensor signals from the front
and rear wheels and also receives signals from other monitor circuits.
1. Buffer chamber (pressurized)
2. Buffer chamber (depressurized)
3. Raised piston
1
2
1
