CLUTCH
5-45
* Apply silicon grease
Disassembling the clutch master cylinder
Order Job/Parts to remove Q’ty Remarks
1 Clutch master cylinder push rod 1
2 Dust boot 1
3 Circlip 1
4Washer 1
5 Clutch master cylinder kit 1
6 Clutch master cylinder body 1
For assembly, reverse the disassembly pro-
cedure.
