SIGNALING SYSTEM
8-31
EAS27290
TROUBLESHOOTING
• Any of the following fail to light: turn signal light, brake light or indicator light.
• The horn fails to sound.
• The fuel meter fails to come on.
• The speedometer fails to operate.
NOTE:
• Before troubleshooting, remove the following part(s):
1. Front cowling assembly
2. Fuel tank
3. T-bar
4. Throttle bodies
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
Checking the signaling system
The horn fails to sound.
NG →
OK ↓
1. Check the fuses.
(Main, ignition, signaling system,
hazard lighting, backup, and ABS
ECU)
Refer to “CHECKING THE FUS-
ES” on page 8-153.
Replace the fuse(s).
2. Check the battery.
Refer to “CHECKING AND
CHARGING THE BATTERY” on
page 8-154.
• Clean the battery terminals.
• Recharge or replace the battery.
3. Check the main switch.
Refer to “CHECKING THE
SWITCHES” on page 8-149.
Replace the main switch/immobilizer unit.
4. Check the entire signaling system
wiring.
Refer to “CIRCUIT DIAGRAM (1/2)”
on page 8-27 and “CIRCUIT DIA-
GRAM (2/2)” on page 8-29.
Properly connect or repair the signaling
system wiring.
Check the condition of each of the sig-
naling system circuits. Refer to
“Checking the signaling system”.
1. Check the horn switch.
Refer to “CHECKING THE
SWITCHES” on page 8-149.
Replace the left handlebar switch.
To Next Page
