Yamaha FJR1300A - Page 437

SIGNALING SYSTEM
8-34
NG →
OK ↓
The shift indicator fails to come on.
NG →
OK ↓
NG →
OK ↓
The oil level warning light fails to come on.
NG →
OK ↓
NG →
OK ↓
The fuel meter fails to come on.
NG →
OK ↓
3. Check the entire signaling system
wiring.
Refer to “CIRCUIT DIAGRAM (1/2)”
on page 8-27 and “CIRCUIT DIA-
GRAM (2/2)” on page 8-29.
Properly connect or repair the signaling
system wiring.
Replace the windshield drive unit.
1. Check the gear position switch.
Refer to “CHECKING THE
SWITCHES” on page 8-149.
Replace the gear position switch.
2. Check the entire signaling system
wiring.
Refer to “CIRCUIT DIAGRAM (1/2)”
on page 8-27 and “CIRCUIT DIA-
GRAM (2/2)” on page 8-29.
Properly connect or repair the signaling
system wiring.
Replace the meter assembly.
1. Check the oil level switch.
Refer to “CHECKING THE OIL
LEVEL SWITCH” on page 8-165.
Replace the oil level switch.
2. Check the entire signaling system
wiring.
Refer to “CIRCUIT DIAGRAM (1/2)”
on page 8-27 and “CIRCUIT DIA-
GRAM (2/2)” on page 8-29.
Properly connect or repair the signaling
system wiring.
Replace the meter assembly.
1. Check the fuel sender.
Refer to “CHECKING THE FUEL
SENDER” on page 8-166.
Replace the fuel pump.
