SIGNALING SYSTEM
8-33
The turn signal light, turn signal indicator light or both fail to blink.
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
The neutral indicator light fails to come on.
NG →
OK ↓
NG →
OK ↓
1. Check the turn signal light bulbs
and sockets.
Refer to “CHECKING THE BULBS
AND BULB SOCKETS” on page
8-152.
Replace the turn signal light bulb, socket or
both.
2. Check the turn signal switch.
Refer to “CHECKING THE
SWITCHES” on page 8-149.
Replace the left handlebar switch.
3. Check the hazard switch.
Refer to “CHECKING THE
SWITCHES” on page 8-149.
Replace the left handlebar switch.
4. Check the turn signal/hazard relay.
Refer to “CHECKING THE TURN
SIGNAL/HAZARD RELAY” on page
8-160.
Replace the turn signal/hazard relay.
5. Check the entire signaling system
wiring.
Refer to “CIRCUIT DIAGRAM (1/2)”
on page 8-27 and “CIRCUIT DIA-
GRAM (2/2)” on page 8-29.
Properly connect or repair the signaling
system wiring.
This circuit is OK.
1. Check the gear position switch.
Refer to “CHECKING THE
SWITCHES” on page 8-149.
Replace the gear position switch.
2. Check the relay unit (diode).
Refer to “CHECKING THE RELAY
UNIT (DIODE)” on page 8-160.
Replace the relay unit.
To Next Page
