ENGINE SPECIFICATIONS
2-8
5th 26/28 (0.929)
Main axle runout limit 0.08 mm (0.0032 in)
Drive axle runout limit 0.08 mm (0.0032 in)
Shifting mechanism
Shift mechanism type Shift drum and guide bar
Shift fork guide bar bending limit 0.100 mm (0.0039 in)
Air filter
Air filter element Dry element
Fuel pump
Pump type Electrical
Model/manufacturer 5JW 21/DENSO
Maximum consumption amperage 6.0 A
Output pressure 324.0 kPa (47.0 psi) (3.24 kgf/cm²)
Fuel injection
Model/quantity INP-151/4
Manufacturer NIPPON INJECTOR
Throttle body
Type/quantity 42EHS/4
Manufacturer MIKUNI
ID mark 3P61 00
Throttle position sensor
Resistance 4.0–6.0 kΩ
Output voltage (at idle) 0.63–0.73 V
Fuel injection sensor
Crankshaft position sensor resistance 421–569 Ω at 20 °C (68 °F)
Cylinder identification sensor output voltage (ON) More than 4.8 V
Cylinder identification sensor output voltage (OFF) Less than 0.6 V
Intake air pressure sensor output voltage 3.75–4.25 V
Coolant temperature sensor resistance 290–354 Ω at 80 °C (176 °F)
Idling condition
Engine idling speed 1000–1100 r/min
Intake vacuum 33.3 kPa (9.8 inHg) (250 mmHg)
Water temperature 100.0–105.0 °C (212.00–221.00 °F)
Oil temperature 80.0–90.0 °C (176.00–194.00 °F)
Throttle cable free play 3.0–5.0 mm (0.12–0.20 in)
Air induction system
Solenoid resistance 19–25 Ω at 20 °C (68 °F)
Shaft drive
Middle gear backlash 0.10–0.20 mm (0.0039–0.0079 in)
Ring-gear-to-stopper-bolt clearance 0.30–0.60 mm (0.0118–0.0236 in)
Ring-gear-to-thrust-washer clearance 0.10–0.20 mm (0.0039–0.0079 in)
Final gear backlash 0.22–0.45 mm (0.0087–0.0177 in)
