STARTER MOTOR
ELECTRIC STARTING SYSTEM IELEclD I
Order
Job name/Part name
Q'ty
Remarks
Starter motor removal
Remove the parts in the order below.
Exhaust pipe assembly
Refer to "ENGINE ASSEMBLY" in
CHAPTER 4.
1
Starter motor/O-ring
1/1
2
Starter motor lead
1
Starter motor disassembly
Disassemble the parts in the order
below.
CD
Front bracket
1
®
Washer kit
1
Refer
to IlSTARTER MOTOR ASSEM-
®
Rear bracket
2
BLY".
@ Shims
1
®
Brush seat/Brush 1 1/1
NOTE:
Be sure to remove the installation nut
on brush
#1 first
®
Armature coil
1
For assembly, reverse the disassembly
procedure.
