14.3 Options and Peripheral Units
14 -63
J
Specifications
The (input) noise filter specifications are shown in the following table. There are two types: Standard spec-
ifications and Counter−EMC models. There are also a simplified models.
200 V Series
Standard Specifications and EMC Conformance Models (manufactured by Schaffner Elec-
tronik AG)
Table14.26 200-V Noise Filter Specifications
Converter
Model
Standard Specifications EMC Conformance Models
Model
CIMR-
MR5j*
Model Code Number No. Current (A) Model No. Current (A)
23P7
FN258L-30-07 FIL001064 1 30 FN258-30/07 1 30
25P5
FN258L-42-07 FIL001065 1 42 FN258-42/07 1 42
27P5
FN258L-55-07 FIL001066 1 55 FN258-55/07 1 55
2011
FN258L-75-34 FIL001067 1 75 FN258-75/34 1 75
2015
FN258L-100-35 FIL001068 1 100 FN258-100/35 1 100
2018
FN258L-100-35 FIL001068 1 100 FN258-100/35 1 100
2022
FN258L-130-35 FIL001069 1 130 FN258-130/35 1 130
2030
FN258L-180-07 FIL001070 1 180 FN258-180/07 1 180
2037
FN359P-250-99 FIL001071 1 250 --- --- ---
* A: For stand-alone drive system N: for NC system
Simplified Models
Table14.27 200-V Simplified Noise Filter Specifications
Converter
Model
CIMR-
MR5j*
Model Code Number No. Current (A)
23P7
LNFD-2303HY 72600-D2303HY 1 30
25P5
LNFD-2203HY 72600-D2203HY 2 40
27P5
LNFD-2303HY 72600-D2303HY 2 60
2011
LNFD-2303HY 72600-D2303HY 3 90
2015
LNFD-2303HY 72600-D2303HY 3 90
2018
LNFD-2303HY 72600-D2303HY 4 120
2022
LNFD-2303HY 72600-D2303HY 4 120
2030
--- --- --- ---
2037
--- --- --- ---
Note: Connect two or more noise filters in parallel.
* A: For stand-alone drive system N: for NC system
