YASKAWA VS-656MR5

Specifications
14.3.7 Noise Filters (Input)
14 -64
400 V Series
Standard Specifications and EMC Conformance Models (manufactured by Schaffner Elec-
tronik AG)
Table14.28 400-V Noise Filter Specifications
Converter
Model
Standard Specifications EMC Conformance Models
Model
CIMR-
MR5j*
Model Code Number No. Current (A) Model No. Current (A)
45P5
FN258L-30-07 FIL001064 1 30 FN258-30/07 1 30
47P5
FN258L-30-07 FIL001064 1 30 FN258-30/07 1 30
4011
FN258L-42-07 FIL001065 1 42 FN258-42/07 1 42
4015
FN258L-55-07 FIL001066 1 55 FN258-55/07 1 55
4018
FN258L-55-07 FIL001066 1 55 FN258-55/07 1 55
4022
FN258L-75-34 FIL001067 1 75 FN258-75/34 1 75
4030
FN258L-100-35 FIL001068 1 100 FN258-100/35 1 100
4037
FN258L-130-35 FIL001069 1 130 FN258-130/35 1 130
4045
FN258L-130-35 FIL001069 1 130 FN258-130/35 1 130
* A: For stand-alone drive system N: for NC system
Simplified Models
Table14.29 400-V Simplified Noise Filter Specifications
Converter
Model
CIMR-
MR5j*
Model Code Number No. Current (A)
45P5
LNFD-4203HY 72600-D4203HY 1 20
47P5
LNFD-4303HY 72600-D4303HY 1 30
4011
LNFD-4203HY 72600-D4203HY 1 40
4015
LNFD-4303HY 72600-D4303HY 1 60
4018
LNFD-4303HY 72600-D4303HY 1 60
4022
LNFD-4303HY 72600-D4303HY 1 90
4030
LNFD-4303HY 72600-D4303HY 1 90
4037
LNFD-4303HY 72600-D4303HY 1 120
4045
LNFD-4303HY 72600-D4303HY 1 120
Note: Connect two or more noise filters in parallel.
* A: For stand-alone drive system N: for NC system
14
