YASKAWA VS-656MR5

Wiring
3.3.1 Wires and Suitable Crimp Connectors
3-8
Notes: 1. Wire size is selected assuming external suspended wiring of single 3-core cables at
an ambient temperature of 30°C (86°
F
)
.
2. If ambient temperature exceeds 30°C (86°
F)
, the allowable current of wire may be lowered.
3. Temperature for each wire indicates the maximum allowable conductor temperature.
Table 3.2 400 V Class Converter Power Cable Specifications
Wire Sizes
Model
CIMR-
MR5
Terminal Symbols
Terminal
Screw
Tighten-
ing
Torque
(N S m)
UL-approved 75°C
(167°F) Temperature-
rated Copper Wire
[AWG (mm
2
)]
600 V Vinyl-
sheath Insulated
Wire (IV, VV)
60°C (140°F)
(mm
2
)
600 V Cross-
linked Polyethy-
lene Wire (IC)
90°C (194°F)
(mm
2
)
600 V Rubber-
insulated Cab-
tyre Cable (CT)
60°C (140°F)
(mm
2
)
P/¨,N/© M6 2.94 (*1)
45P5
R/L1, S/L2, T/L3 M5 2.35 14 (2.1) 2 2 2
45P5
A1/r, A2/t M5 2.35 14 (2.1) 2 2 2
M4 1.2 to 2.0 10 (5.3) 2 2 2
P/¨,N/© M6 2.94 (*1)
47P5
R/L1, S/L2, T/L3 M5 2.35 14 (2.1) 2 2 2
47P5
A1/r, A2/t M5 2.35 14 (2.1) 2 2 2
M4 1.2 to 2.0 10 (5.3) 2 2 2
P/¨,N/© M6 × 2 2.94 (*1)
401
1
R/L1, S/L2, T/L3 M6 3.4 to 4.9 12 (3.3) 3.5 2 3.5
4011
A1/r, A2/t M4 1.2 to 2.0 14 (2.1) 2 2 2
M6, M6 3.4 to 4.9 10 (5.3) 3.5 2 2
P/¨,N/© M6 × 2 2.94 (*1)
4015
R/L1, S/L2, T/L3 M6 3.4 to 4.9 10 (5.3) 3.5 2 3.5
4015
A1/r, A2/t M4 1.2 to 2.0 14 (2.1) 2 2 2
M6, M6 3.4 to 4.9 10 (5.3) 3.5 2 3.5
P/¨,N/© M6 × 2 2.94 (*1)
4018
R/L1, S/L2, T/L3 M6 3.4 to 4.9 8 (8.4) 5.5 3.5 5.5
4018
A1/r, A2/t M4 1.2 to 2.0 14 (2.1) 2 2 2
M6, M6 3.4 to 4.9 10 (5.3) 5.5 3.5 3.5
P/¨,N/© M6 × 2 2.94 (*1)
4022
R/L1, S/L2, T/L3 M6 3.4 to 4.9 8 (8.4) 8 3.5 8
4022
A1/r, A2/t M4 1.2 to 2.0 14 (2.1) 2 2 2
M6, M6 3.4 to 4.9 8 (8.4) 5.5 3.5 5.5
P/¨,N/© M6 × 2 2.94 (*1)
4030
R/L1, S/L2, T/L3 M6 3.4 to 4.9 6 (13.3) 14 5.5 14
4030
A1/r, A2/t M4 1.2 to 2.0 14 (2.1) 2 2 2
M6, M6 3.4 to 4.9 8 (8.4) 8 5.5 5.5
P/¨,N/© M6 × 2 2.94 (*1)
4037
R/L1, S/L2, T/L3 M6 3.4 to 4.9 4 (21.2) 22 8 22
4037
A1/r, A2/t M4 1.2 to 2.0 14 (2.1) 2 2 2
M6, M6 3.4 to 4.9 6 (13.3) 8 5.5 8
P/¨,N/© M6 × 2 2.94 (*1)
4045
R/L1, S/L2, T/L3 M6 3.4 to 4.9 4 (21.2) 22 14 22
4045
A1/r, A2/t M4 1.2 to 2.0 14 (2.1) 2 2 2
M6, M6 3.4 to 4.9 6 (13.3) 14 8 8
4011 to
4045
A11/r1, A21/t1 (*2) M4 1.2 to 2.0 14 (2.1) 2 2 2
* 1. Connect using exclusive-use connection bus bar.
* 2. Provided for open chassis type with a minimum capacity of 11 kW. Not provided for external heatsink cooling type.
Notes: 1. Wire size is selected assuming external suspended wiring of single 3-core cables at
an ambient temperature of 30°C (86°
F
)
.
3
